Set of TT01 - Rp 4.250.ooo (Nego)Set of FUTABA 2PL 2-Channel AM/2 S3003 ServosFEATURES:
Chassis: TT-01 plastic tub design Drive: Four wheel shaft driven Shocks: Plastic bodied friction type Gearboxes: Sealed Differentials: Planetary gear Transmission: Single-speed Light Unit: TLU-01, head and tail lights turn on automatically when car is switched ON Tires: Radial racing, 1" (26mm) wide 2" (50.8mm) inner diameter Wheels: 5-spoke plastic Black in color, 1" (25.4mm) wide 1.9" (48mm) diameter Speed Control: TEU-101 BK with reverse, Body: 2-door coupe, constructed of polycarbonate also includes wing, mirrors head light and tail light detail Bumper: Front foam Suspension: Four wheel independent double wishbone Camber Tie Rods: Fixed, non-adjustable Steering Tie Rods: Fixed, non-adjustable Steering: Bellcrank type
This is the Futaba 2PL AM Computer Radio system with two S3003
and the R152JE Receiver.
FEATURES: One-button programming for fast and easy menu access
Ten model memory stores and selects preset programming for up to ten
different models
One trim switch allows setting and adjusting trims without returning
to the menu
Steering dual rate strategically located on the grip close to the
trigger offers more mid-range control, crucial when cars are going
into corners
Steering/ End Point Adjustment (EPA) limits servo travel for
more control and to prevent servo damage
ABS braking initiates ON and OFF pulsing for less skidding and can be
set for slow, mid, or fast pulsing
One Year Warranty
INCLUDES: One 2PL Magnum Transmitter with crystal
One R152JE receiver with crystal
Two S3003 Standard with installed X style servo horns.
One Switch Harness
Two Servo Accessory packs
One 4-cell Receiver battery holder
Instruction Manual
REQUIRES: 8 AA NiCds for the transmitter
4 AA NiCds for the receiver (order 1 FUGP7300)
SPECS: S3003 Servo
Speed: .23 sec/60° @ 4.8V or .19 sec/60° @ 6V
Torque: 44.3 oz-in @ 4.8V or 56.8 oz-in @ 6V
Size: 1.59"L x .78"W x 1.42"H (40.4x19.8x36mm) w/o output
shaft
Weight: 1.31oz (37.2g)
Connector: "J" type with approx. 5" lead
R152JE Receiver
Length: 1.65" (42mm) Receiving Frequency: 75MHz
Width: 1.10" (28mm) Intermediate Frequency: 455kHz
Height: .67" (17mm) Power Requirement: 4.8-6V shared w/servo
Weight: .59oz (16.7g) Current Drain 12mA (at No signal)
PERFORMANCE KITS FOR SALE- ESC SPEED CONTROLLER - Rp 560.000- TAMIYA RS540 SPORT TUNED 49/62 - Rp 700.000- TAMIYA SUPER STOCK TZ - Rp 400.000
